产品描述：

★利用多普勒效应原理，自主研发平面天线发射接收电路，智能检测周围电磁环境，自动调整工作状态；

★静止时超低照明功耗，一般为0.5-2.5W，并且根据环境可调；

★人体或汽车移动进入时，自动感应满负荷工作，10-18W（0.6或1.2米灯具）

★满载工作时间：2秒-60秒根据环境可调，感应灵敏度：6-10米；

★日平均功耗：4.8W；(按工作8小时，静止16小时计，满负荷10W)

宽电压输入，高效率≥0.89(≤100mA时)

★输入特性：宽电压、宽频率输入、低谐波。

★电气方面：灯管内置采用非隔离高效恒流驱动电源精度小于2%无温漂。

★灯管型材：灯管主体采用优质合金材料,不易变形，光源采用铝基板导热，散热效果好。

★灯管光效：光源选用高档 LED 芯片、多灯珠、光效高、均匀好、无频闪，长寿命。

★安全方面：设计严格按照SAA  UL 标准。

★环保、安全、无污染、符合RoHS 规范。

Lamp holder: G13

Beam angle: >160°

Power factor: ≧0.9

LED power/number of LEDs/(LED2835): 0.2W

Total power consumption of lamps: 18W

Central illumination of lamp: 90lux

Correlated color temperature: □2700-3200K □4500-5000K □6000-6500K

Display index: >75

Luminous efficiency: 98.5lm/w

Working environment temperature: -20℃～60℃

Working humidity: 10%~60%RH

Storage temperature: -25℃～60℃

Lamp body and lampshade: aluminum alloy + PC cover (fog)

Protective lighting: IP20

Product net weight: 292G

Net box: 1.7KG

Packing quantity: 50PCS

Gross weight: 15.394KG

Box size: 1260*440*280mm



product description:

1. Product specifications are: 0.6 meters -1.5 meters

2. When a person or other animal enters, it automatically senses full load work, 19W full load work, sensing sensitivity time: 10 seconds ± 10%,

3. Sensitivity distance: 6-10 meters

 (2) Working mode of LED smart tube

1. Use a human body sensor to control every human body-sensing LED fluorescent tube in the corridor or other specific places. When no people/other animals enter or leave,

All fluorescent lamps are in the off state (customized according to customer requirements), which greatly saves electricity.

(According to past experience, 24-hour electricity-using places such as garages can save about 80% of electricity)

2. When someone/other animal enters and exits, the human body sensor in the corresponding area sends out a signal, and the dormant LED tube is awakened to light up, the power is full power, and it lights up.

The brightness reaches the brightness of 60W ordinary fluorescent lamp, which is convenient for car owners to stop. When the car or people are moving in the sensing area, the LED fluorescent tube always keeps on.

After the car or person leaves the sensing area for about 30 seconds, the LED lights automatically re-enter the non-lighting state, and the power consumption of each tube is between 0.9-1.0W (according to customer requirements

Request customization)



(3) Installation requirements and maintenance

 1. The product installation is just like the installation method of ordinary household fluorescent lamps.

2. The power must be cut off before installation, please do not operate with power.

 3. Make sure that the product is firmly installed before powering on
